50mm-600mm Diameter Ceramic Anilox Roller Gravure Roller High Precision

Brand Name:	HUATAO
Model Number:	HTCAR
MOQ:	1
Price:	2000USD/pc-5000USD/pc
Delivery Time:	50 DAYS
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

ISO CE

Product Name:

High Precision Ceramic Gravure Roller 1 Year Warranty

Key Words:

Coating Roller, Anilox Roller,Gravure Roller, Cermaic Gravure Roller

Flow Channel::

Channels Between Inner And Outer Tube Separated With Welded Leading Spiral

Effective Engraving Diameter:

50-600mm

Roller Body Material::

45#

LPI:

110～2000 L/in (4～800 L/cm)

Surface Treatment::

Ceramic Engraving

Coating Hardness:

HV0.3≥1200

Packaging Details:

WOODEN CASE

Supply Ability:

100PCS/MONTH

Highlight:

600mm Diameter Ceramic Anilox Roller

50mm Diameter Ceramic Anilox Roller

Gravure Roller High Precision

Product Description

High Precision Ceramic Gravure Roller 50-600mm Diameter

High Precision Ceramic Gravure Roller 1 Year Warranty

Ceramic Gravure Roller Introduction

Our ceramic laser-engraved gravure roller series combines cutting-edge technology with premium materials, delivering exceptional performance for various printing and coating applications.

High-Precision Laser Engraving for Customization

Using German fiber laser engraving equipment and proprietary technology, our rollers achieve unparalleled precision:

Diverse Mesh Shapes: Customizable geometries (hexagonal, quadrangular) to adapt to specific ink or coating properties
Adjustable Line Counts & Angles: Supports 30°, 45°, 60° arrangements to optimize transfer efficiency and pattern clarity

Advanced Coating Technology for Superior Durability

Our laser engraving process uses 100% imported chromium oxide powder for:

Enhanced Strength: Resists deformation under high-pressure operation
Ultra-Density: Minimized porosity prevents leakage for uniform transfer
Exceptional Hardness: 30%-50% longer service life than traditional metal rollers

Ceramic Gravure Roller Applications

Widely used in packaging and printing industries including carton ink printing machines, flexographic printers, anodized aluminum processing, composite films, lithium batteries, and precision coating machines.

High-speed, high-efficiency operation performance
Denser, finer ceramic coating for smooth surface finish
Optimal opening-to-depth ratio for maximum volume per unit area
Excellent release and transfer properties for uniform layers
Precise mesh pattern accuracy for controllable transfer volume
Multiple network types available for different transfer needs

Product Specifications

Parameter	Specification
Effective engraving diameter	φ50-600mm
Effective engraving length	1100-4000mm
Engraving lines	110-2000 L/in (4-800 L/cm)
Mesh shape	Hexagonal, square concave/convex points, twill types
Mesh arrangement angle	160°, 45°, 30°, or custom angles

Quality Accuracy

Coating porosity: 1-3%
Coating hardness: HV0.3≥1200
Circle runout: 0.005
Cylindricity: 0.01
Dynamic balancing quality level: G2.5

Selection based on equipment properties, ink/glue characteristics, and printing material requirements. Custom mesh types available for special needs.

About Huatao Group

Founded in 2008, Huatao Group is a professional supplier of industrial rollers with over 15 years of experience serving paper, rubber, plastic, and nonwoven fabric industries. Our products are exported to 96+ countries with excellent reputation.

Key Products:

Paper Industry: Forming rollers, vacuum couch rollers, press rollers, dryer cylinders
Plastic & Rubber: Chill rollers, corona treatment rollers, anilox rollers, gravure rollers
Nonwoven Fabric: Cylinder rollers, embossing rollers, cooling rollers

We are committed to innovation, reliability, and customized solutions to meet diverse industrial requirements.
